Description
24V 50Ah LifePo4 Battery
Looking for a compact, powerful, and dependable energy source for your mobile applications? Our HMX 24V 50Ah LiFePO4 battery is engineered to deliver exceptional performance in a versatile and lightweight package. With a substantial 1280Wh of energy and advanced Lithium Iron Phosphate technology, this LiFePO4 battery 24V 50Ah is the perfect power solution for a wide range of uses, from recreational vehicles to renewable energy systems.
Why Choose Our 24V 50Ah LiFePO4?
Long-Lasting Reliability: Experience a cycle life of over 2000 cycles while maintaining 80% of its original capacity. This 24v lifepo4 battery 50ah is built for the long haul, providing a superior lifespan compared to traditional batteries.
Versatile Application: Whether you’re powering a boat, enjoying RV camping, operating a golf cart, running a lawnmower, or storing solar energy, this LiFePO4 24V 50Ah battery is designed to meet your needs. Its robust performance makes it an ideal choice for both leisure and professional use.
Maintenance-Free & Safe: With a very low self-discharge rate of ≤3.5% per month, the battery holds its charge for longer periods when not in use. The stable LiFePO4 chemistry ensures enhanced safety and reliable operation across a wide temperature range.
Rugged Build: The IP55 rating protects against dust and water jets, making this LiFePO4 battery 24V 50Ah durable enough to handle tough outdoor conditions. Its compact dimensions (330*172*215 mm) and lightweight design (approx. 10kg) allow for easy installation and integration.
Technical Specifications:
Nominal Voltage: 25.6V (Fully compatible with 24V systems)
Nominal Capacity: 50Ah
Energy: 1280Wh
Max. Continuous Discharge Current: 50A
Cycle Life: 2000+ Cycles
Protection Rating: IP55
Terminals: M8
We also provide other 24V LifePo4 Battery, 12V LifePo4 Battery or 50Ah LifePo4 Batterys.
| Electrical Characteristics | Nominal Voltage | 25.6V | ||||||||||||||||||||||
| Nominal Capacity | 50Ah | |||||||||||||||||||||||
| Energy | 1280Wh | |||||||||||||||||||||||
| Internal Resistance | ≤35mΩ | |||||||||||||||||||||||
| Cycle Life | 2000 Cycles @ 0.2C Charging/Discharging ,Until 80% Capacity | |||||||||||||||||||||||
| Self Discharge | ≤3.5% per month at 25℃ | |||||||||||||||||||||||
| Standard Charging | Max.Charging Voltage | 28.0~29.2V | ||||||||||||||||||||||
| Charging Mode | At 0℃~45℃ temperature, charged to 14.6V at a constant current of 0.2C, and then,changed continuously with constant voltage of 14.6V until the current was not more than 0.02C | |||||||||||||||||||||||
| Charging Current | 20A | |||||||||||||||||||||||
| Max.Charging Current | 20A | |||||||||||||||||||||||
| Standard Discharging | Discharging Current | 50A | ||||||||||||||||||||||
| Max. Continuous Current | 50A | |||||||||||||||||||||||
| Max.Pulse Current | 100A(<3S） | |||||||||||||||||||||||
| Discharging Cut-off Voltage | 10.0 | |||||||||||||||||||||||
| Operating Condition | Charge Temperature | 0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity | ||||||||||||||||||||||
| Discharge Temperature | -20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity | |||||||||||||||||||||||
| Storage Temperature | 0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity | |||||||||||||||||||||||
| Water Dust Resistance | IP55 | |||||||||||||||||||||||
| Structure | Cell & Format | LFP3.2V50Ah (4S1P) | ||||||||||||||||||||||
| Casing | Plastic | |||||||||||||||||||||||
| Dimension(L*W*H*TH) | 330*172*215 mm | |||||||||||||||||||||||
| Package Dimension | 360*210*260 mm | |||||||||||||||||||||||
| Weight | Approx. 10Kg | |||||||||||||||||||||||
| Terminal | M8 | |||||||||||||||||||||||
Power Your Adventures and Projects
Equip your RV, marine vessel, or off-grid solar system with the efficiency and reliability of our 24V 50Ah LiFePO4 battery. This LiFePO4 24V 50Ah unit is the smart choice for anyone needing a clean, quiet, and maintenance-free power source.
Upgrade to a smarter energy solution today!
