Description
| Main Parameters | ||
|---|---|---|
| Model | H096-15KWh | |
| Basic parameter | ||
| Size（LW H） | L460mmW245mmH760mm | |
| Weight | 120 kg | |
| Installation Way | floor type | |
| Working Temperature Range | -10℃~+50℃ | |
| Standby Power | < 10 W | |
| Type of Cooling | natural cooling | |
| Protection Class (according to IEC 60529) | ||
| Climate Type (according to IEC 60721 – 4 – 4) | Below 4000M above sea level | |
| Operating Humidity Range | 5~95% | |
| Display and communication | ||
| User interaction interface | LCD | |
| Method of communication | RS485/CAN | |
| Modular | Item | Parameter |
| Battery | Battery Specifications | Model : 71173204 – 280Ah |
| Battery Type | LiFePO4 | |
| Nominal Capacity | 280.0Ah (Typical) | |
| Impedance | ≤0.40mΩ | |
| Battery system | Battery Matching Method | 1P16S |
| Nominal Capacity | 280.0Ah (Typical) | |
| Nominal Voltage | 51.2V | |
| Charge Cutoff Voltage | 58.4V | |
| Charge Current | 140.0A Standard | |
| Discharge Cutoff Voltage | 40.0V | |
| Cycle Life | 6000 times | |
| Discharge Current | Standard：140.0A; Max. Continuous：280.0A |
